مشخصات و کاربرد بریر ایزولاتور D5014D ورودی آنالوگ 4 تا 20 میلی آمپر، قابل استفاده در ترانسمیترهای 2 و 4 سیمه SIL3
بریر مدل D5014D شرکت GMI
دو کاناله، ورودی آنالوگ برای ترانسمیرترهای 2 و 3 و 4 سیمه کاربرد دارد.
ماژول منبع تغذیه تکرارکننده (Repeater Power Supply) مدل D5014D یک رابط ورودی آنالوگ با یکپارچگی/اطمینانپذیری بالا است که برای کاربردهایی مناسب است که در سیستمهای مرتبط با ایمنیِ صنایع پرریسک، سطح SIL 3 را نیاز دارند. این ماژول یک منبع تغذیه DC کاملاً ایزوله برای تغذیه ترانسمیترهای متداول ۲ سیمه ۴–۲۰ میلیآمپر (اکتیو یا پسیو) که در ناحیه خطرناک (Hazardous Area) قرار دارند فراهم میکند و جریان را در یک مدار شناور تکرار میکند تا یک بار (Load) در ناحیه ایمن (Safe Area) را راهاندازی کند. این ماژول از تکثیر جریان خروجی پشتیبانی میکند و همچنین امکان عبور سیگنالهای ارتباطی دوطرفه را برای تجهیزات HART® فراهم میسازد. SIL3 و قابلیت استفاده به عنوان Duplicator (یک ورودی و دو خروجی) را دارد.
کاربرد: ورودی آنالوگ
Environmental conditions
- Operating temperature
- temperature limits –40 to +70 °C.
- Storage temperature
- temperature limits –45 to +80 °C.
Input
- Type
- 4 to 20 mA (separately powered input, voltage drop ≤ 0.5 V) or 4 to 20 mA (2 wires Tx current limited ≈ 25 mA), reading range 0 to 24 mA.
- Transmitter line voltage
- 15.0 V typical, 14.5 V minimum, @ 20 mA.
Isolation
- Test Voltage
- I.S. In/Out 2.5 kV; I.S. In/Supply 2.5 kV; I.S. In/I.S. In 500 V; Out/Supply 500 V; Out/Out 500 V.
Mounting
- Type
- DIN-Rail 35 mm, with or without Power Bus or on custom Term. Board.
- Weight
- about 155 g
- Connection
- by polarized plug-in disconnect screw terminal blocks to accommodate terminations up to 2.5 mm² (13 AWG).
- Dimensions
- Width 12.5 mm, Depth 123 mm, Height 120 mm.
Output
- Type
- 4 to 20 mA, on max. 550 Ω load in source mode (typical 12 V compliance); V min. 8 V @ 0 Ω load V max. 30 V in sink mode, current limited ≈ 25 mA or 1 to 5 V on internal 250 Ω shunt. Output current duplication available (D5014D).
- Response time
- 5 ms (0 to 100 % step change).
Performance
- Ref. Conditions
- 24 V supply, 250 Ω load, 23 ± 1 °C ambient temperature.
- Calibration accuracy
- ≤ ± 0.1 % FSR.
- Linearity accuracy
- ≤ ± 0.05 % FSR.
- Temp. influence
- ≤ ± 0.01 % FSR on zero/span for a 1 °C change.
Safety description
- Equipment
- Associated apparatus and non-sparking electrical equipment.
- Safety parameters
- Uo = 25.9 V, Io = 92 mA, Po = 594 mW at terminals 7-8, 9-10.
Uo = 1.1 V, Io = 56 mA, Po = 16 mW at terminals 8-11, 10-12.
Ui = 30 V, Ii = 128 mA, Ci = 0 nF, Li = 0 nH at terminals 8-11, 10-12.
Um = 250 Vrms or Vdc, -40 °C ≤ Ta ≤ 70 °C.
Supply
- Voltage
- 24 Vdc nom (18 to 30 Vdc), reverse polarity protected
- Current Consumption
- 90 mA @ 24 Vdc with 20 mA out, typical.
- Power Dissipation
- 1.35 W @ 24 Vdc with 20 mA out, typical.
